Product Brief
Side-opening access saves time, heavy cargo loading/unloading is effortless, it's highly adaptable for multi-category transportation, and logistics efficiency doubles!
Product Details
Based on the standard enclosed compartment, the side-opening box-type semi-trailer is a specialized model that achieves "efficient loading/unloading" and "flexible adaptability" by optimizing the side door opening structure.
It uses Q345B high-strength steel as the core material; the frame and door frame are welded as a single unit, balancing lightweight performance and torsion resistance. EPDM (Ethylene Propylene Diene Monomer) sealing strips are embedded at the compartment joints, achieving IPX5-level water resistance.
Technically, it adopts a multi-door design: hydraulic single-doors enable effortless opening, while manual double-doors cover 80% of the compartment length. The door frames are reinforced with 300-500mm stiffeners to prevent deformation. Optional configurations include foldable access ramps and layered shelves. It is widely used in scenarios involving transportation of multi-category cargo across multiple stops.
Product Parameters
|
Parameter |
Specifications |
|
Length (mm) |
13000, 13750, 15000 |
|
Width (mm) |
2500, 2550 |
|
Height (mm) |
3600, 3800, 4000, 4200 |
|
Rated Load Capacity |
32T, 36T, 50T, 80T |
|
Number of Axles (Optional) |
3-axle, 4-axle, 5-axle |
|
Style |
Side-opening |
|
Body Material |
Carbon steel |
Product Advantages
The advantages of the side-opening model focus on three aspects: "loading/unloading efficiency", "scenario compatibility" and "cargo protection".
Loading/unloading efficiency is increased by 30%-50%.
Suitable for transporting large/irregular-shaped cargo, such as sand and gravel, coal, home appliances (refrigerators, washing machines), and furniture (sofas, wardrobes). With fully open dual-side access, forklifts can load/unload horizontally directly from the side, reducing the cargo damage rate by over 60%.
Product Application Scenarios
It focuses on meeting the transportation needs of "high frequency and multi-category". The application scenarios of the side-opening box-type semi-trailer are highly concentrated in fields that "require frequent loading/unloading and involve diverse cargo types".
